Zebra TC2X Series Android Mobile Computer (TC21/TC26)
Zebra TC2X Series Android Mobile Computer (TC21/TC26)
SKU:
The Zebra TC2X series covers Zebra's TC21 and TC26 Android touch computers. The TC21 is the Wi-Fi model, and the TC26 adds a cellular WWAN (LTE) radio and GPS. Both share a 5-inch HD touchscreen, integrated NFC, barcode capture and IP67 sealing. This listing is for the TC2X family; a specific factory configuration is not listed.
Key features
- Two models: the TC21 with WLAN, Bluetooth and USB, and the TC26 with the same connections plus WWAN (LTE Category 6) and GPS
- 5.0-inch color HD (1280 x 720) display with Corning Gorilla Glass and capacitive multi-touch
- Barcode capture with an SE4100 or SE4710 1D/2D imager, or camera-based scanning on select configurations
- Wi-Fi 802.11 a/b/g/n/ac, Bluetooth 5.0 (BLE) and integrated NFC
- Removable, serviceable Li-Ion battery in standard (3,300 mAh or more) or extended (5,260 mAh) capacity
- IP67 sealing and 4 ft (1.2 m) drops to concrete across the operating temperature range
Specifications
| Models | TC21 (WLAN) and TC26 (WLAN plus WWAN) |
|---|---|
| Operating system | Android; Zebra's current specification sheet lists both models as upgradeable to Android 14 |
| Processor | Qualcomm Snapdragon 660 octa-core, 1.8 GHz or 2.2 GHz depending on configuration |
| Memory | Depends on configuration (not specified for this listing) |
| Display | 5.0 in. color HD, 1280 x 720, LED backlight, Corning Gorilla Glass |
| Data capture | SE4100 or SE4710 1D/2D imager, or camera scanning (configuration dependent) |
| Cameras | 13 MP rear; 5 MP front camera optional |
| WLAN | IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w, 1x1 MU-MIMO |
| WWAN and GPS | TC26 only: LTE Category 6; GPS with A-GPS, GLONASS, BeiDou and Galileo |
| Bluetooth and NFC | Bluetooth 5.0 BLE, Class 2; integrated NFC |
| Expansion | microSD slot, up to 128 GB |
| Battery | Removable Li-Ion: standard 3,300 mAh or more, or extended 5,260 mAh |
| Dimensions | 6.22 x 3.11 x 0.54 in (158 x 79 x 13.7 mm) with standard battery; 0.68 in (17.3 mm) deep with extended battery |
| Weight | 8.32 oz (236 g) with standard battery; 269 g with extended battery |
| Sealing | IP67 |
| Drop | 4 ft (1.2 m) to concrete per MIL-STD-810G across the operating temperature range; 5 ft (1.5 m) with optional protective boot |
| Operating temperature | 14°F to 122°F (-10°C to 50°C) |
Frequently asked questions
What is the Zebra TC2X series?
TC2X is shorthand for the Zebra TC21 and TC26 touch computers, and Zebra uses "TC2X" in accessory part numbers made for both models. The TC26 adds WWAN and GPS to the TC21's feature set.
What is the difference between the TC21 and the TC26?
The TC21 connects over Wi-Fi, Bluetooth and USB. The TC26 adds a WWAN radio (LTE Category 6) and GPS, and Zebra lists an optional eSIM for the TC26 only. Zebra lists the same display, sealing, drop rating and scanning options for both models.
Which configuration does this listing include?
This listing covers the TC2X family and does not specify a factory configuration, such as TC21 or TC26 model, memory, scan engine, battery or region. Confirm the exact Zebra part number before ordering if your deployment depends on a specific configuration.
Which Android version does the TC21/TC26 run?
The installed Android version depends on the unit's configuration and software build. Zebra's current specification sheet lists both the TC21 and the TC26 as upgradeable to Android 14.
How durable is the TC2X series?
Zebra specifies IP67 sealing, 4 ft (1.2 m) drops to concrete per MIL-STD-810G across the operating temperature range, 5 ft (1.5 m) drops with the optional protective boot, and 550 tumbles at 1.6 ft (0.5 m) with the boot.
