Sato
Sato, SG112-ex, 10.5" Industrial Thermal Label Printer
Sato, SG112-ex, 10.5" Industrial Thermal Label Printer
SKU:WWSG04001
Product Description
The SATO SG112-ex is a high-performance 10.5-inch industrial thermal label printer designed for organizations that require extra-wide, high-resolution labels for compliance, logistics, manufacturing, and warehouse operations. Supporting both Direct Thermal and Thermal Transfer printing, the SG112-ex produces crisp 305 dpi labels up to 10.5 inches wide at speeds of up to 6 inches per second, making it ideal for pallet labels, GHS chemical labels, automotive labels, lumber tags, and other large-format applications.
Built with SATO's industrial reliability, the SG112-ex features multiple connectivity options, a large multilingual LCD display, intuitive operation, and support for roll or fan-fold media. Whether printing a single oversized label or multiple smaller labels across the print width, the SG112-ex delivers outstanding accuracy and productivity in demanding industrial environments.
Key Features
- Prints labels up to 10.5" (266.7 mm) wide
- 305 dpi high-resolution print quality
- Supports Direct Thermal and Thermal Transfer printing
- Print speeds up to 6 ips (150 mm/sec)
- Standard USB, Ethernet, Serial, Parallel, EXT, and SD card interfaces
- Large multilingual LCD display with status LEDs
- Available in Standard and Factory Cutter models
- Supports roll and fan-fold label media
- Rugged industrial metal construction
- Compatible with Windows, Linux, and macOS printer drivers
- Supports SATO All-In-One configuration utility
- Optional RTC, Catch Tray, and Unwind Unit accessories available
Ideal For
- Manufacturing
- Distribution Centers
- Warehousing
- Logistics & Transportation
- Chemical & GHS Labeling
- Lumber & Forestry
- Automotive Manufacturing
- Paper & Pulp Industry
- Asset Identification
- Large Shipping Labels
- Pallet Labels
- Compliance Labels
- Multiple-up Label Printing
Common Applications
- Pallet identification labels
- GHS chemical labels
- Large warehouse location labels
- Automotive compliance labels
- Lumber and timber tags
- Export and logistics labels
- Multi-label sheet printing
- Manufacturing process labels
- Industrial asset labels
- Oversized inventory labels
Product Specifications
| Specification | Details |
|---|---|
| Print Method | Direct Thermal & Thermal Transfer |
| Resolution | 305 dpi |
| Maximum Print Width | 10.5" (266.7 mm) |
| Maximum Print Length | 16.5" (420 mm) |
| Maximum Print Speed | 6 ips (150 mm/sec) |
| Memory | 40 MB Flash / 64 MB RAM |
| Media Width | 5.15"–11.8" (131–300 mm) |
| Maximum Roll Diameter | 8" OD |
| Ribbon Length | Up to 300 m |
| Connectivity | USB 2.0, Ethernet, RS-232 Serial, IEEE1284 Parallel, EXT, SD Card Slot |
| Display | 3.3" Color LCD |
| Print Modes | Continuous, Tear-Off, Cutter (Cutter Models) |
| Printer Languages | SBPL |
| Weight | 44.1 lbs (Standard), 51 lbs (Cutter) |
Available Variants
| SATO SKU | Media Handling |
|---|---|
| WWSG04001 | Standard (Tear-Off) |
| WWSG0400N | Standard (Tear-Off) |
| WWSG0410N | Factory Cutter |
Connectivity
All SG112-ex models include:
- USB 2.0
- Ethernet (LAN)
- RS-232 Serial
- IEEE1284 Parallel
- EXT Port
- SD Card Slot
Compatible Media
- Die-cut labels
- Continuous labels
- Fan-fold labels
- Synthetic labels
- Paper labels
- Polypropylene labels
- Polyester labels
- Thermal Transfer ribbons
- Direct Thermal labels
Why Choose the SATO SG112-ex?
The SG112-ex is purpose-built for organizations needing extra-wide industrial labels without sacrificing print quality or speed. Its combination of 305 dpi precision, 10.5-inch print width, robust connectivity, and industrial durability makes it an excellent solution for high-volume production environments where oversized labels are essential.
